PCB Design

We design custom printed circuit boards — from single-layer prototypes to high-density multilayer production boards — engineered for signal integrity, thermal performance, and manufacturability.

Start a Project Our Capabilities

What We Design

Single, double & multilayer PCB design (up to 16 layers)

Schematic capture & BOM generation

Signal integrity analysis and controlled impedance routing

High-speed digital, RF, and mixed-signal board design

Design for Manufacturability (DFM) review & Gerber export

Prototype to production — component sourcing support

Tools & Standards

EDA Tools: Altium Designer, KiCad, Eagle
Simulation: LTSpice, HyperLynx SI/PI, ANSYS
Standards: IPC-2221, IPC-7351, RoHS, REACH
Deliverables: Gerber, ODB++, BOM, assembly drawings
Layer count: 2–16 layers, up to 0.1mm trace/space
Output formats: PDF schematics, 3D STEP models, pick-and-place files

First-Pass Success

Our rigorous DFM checks and pre-layout simulation mean fewer spins, lower prototype costs, and faster time to market.

All designs include Gerber files, BOM, and assembly drawings ready for any PCB fab.

Delivery Process

1Schematic capture & component selection (Week 1)
2Layout & routing with DFM checks (Week 2–3)
3Review, simulation & sign-off (Week 3–4)
4Gerber export & fab support (Week 4)

Pricing Guide

2-layer prototype board — from ₹15,000
4-layer board with DFM — from ₹30,000
High-speed / RF design — from ₹60,000
Full product design (schematic + layout) — custom quote

Get a Quote
